pro-xi®
Specifications
| MECHANICAL | |
|---|---|
| Height | 5.25” (13.34 cm) 3RU |
| Width | 17” (43.18 cm) chassis 19” rack mount standard |
| Depth | 19.5” (49.53 cm) bezel–latch |
| Weight | 42 lbs |
| INCOMING SYSTEM CARD (ISC) | |
|---|---|
| Input Video | DVI Single-Link, DVI Dual-Link, HDMI, VGA |
| Max Input Resolution | 2048 x 1536 @ 60Hz |
| HDCP | Not supported |
| Power Consumption | 24 VA Max |
| Max # of Cards / Frame | 8 |
| Redundancy | Yes |
| Audio In Connector | 3.5mm stereo (TRS) female |
| USB Connector | Two USB Type ‘B’ female |
| Video In Connector | DVI-I Single/Dual Link female (HDMI and VGA with adapter) |
| VIDEO OUTPUT CARD (VOC) | |
|---|---|
| Output Video | DVI-D Single-Link, DVI-D Dual-Link, and HDMI |
| Max Output Resolution | 2560 x 1600 @ 60Hz |
| Power Consumption | 21 VA Max |
| Max # of Cards / Frame | 2 |
| Redundancy | Yes |
| Video Output Connector | DVI-D Single / Dual-Link female (HDMI with adaptor) |
| CONTROLLER CARD (CTC) | |
|---|---|
| Network | Ethernet, 10-100 Mb/s |
| Power Consumption | 24 VA Max |
| Audio Out Connector | 3.5mm (TRS) female |
| Ethernet Connector | RJ45 CAT5 female |
| USB Connector | Three USB Type ‘A’ female |
| CABLING (Recommended Maximums) | |
|---|---|
| DVI Cables | 16.4’ (5m) 24AWG |
| VGA Cables | 16.4’ (5m) 24AWG |
| USB Cables | 16.4’ (5m) |
| RESOLUTIONS | |
|---|---|
| Output Resolutions | 1920 x 1080 @ 60 HZ 1920 x 1200 @ 60 HZ 2048 x 1152 @ 60 HZ 2048 x 1280 @ 60 HZ 2048 x 1536 @ 60 HZ 2560 x 1440 @ 60 HZ 2560 x 1600 @ 60 HZ |
| Input Resolutions | 640 x 480 @ 60 and 75 Hz 800 x 600 @ 60 and 75 Hz 1024 x 768 @ 60 and 75 Hz 1280 x 800 @ 60 and 75 Hz 1280 x 1024 @ 60 and 75 Hz 1600 x 1200 @ 60 Hz 1600 x 1050 @ 60 Hz 1920 x 1080 @ 60 Hz 1920 x 1200 @ 60 Hz 2048 x 1152 @ 60 Hz 2048 x 1280 @ 60 Hz |
| NETWORK CONNECTIVITY | |
|---|---|
| Ports | RJ45 |
| Protocols | 10/100Mb/s Ethernet |
| ENVIRONMENTAL | |
|---|---|
| Operating Temp | 10 – 40 Degrees C |
| Humidity | 0-90% (non-condensing) |
| Input Voltage | 100-240 VAC |
| Redundancy | Dual redundant power supplies, dual redundant power paths |
| Line Frequency | 50-60 Hz |
| Power Consumption | 300 VA Max |
