Carbonite Mosaic
Specifications
Inputs & Outputs
| INPUTS & OUTPUTS | CARBONITE MOSAIC |
|---|---|
| SDI Inputs | 36 inputs (3G HD-SDI) |
| SDI Outputs | 25 outputs (3G HD-SDI) – 3 of these outputs are dedicated to the input source monitoring MultiViewers. |
| Input Processing | Video proc amps, color correction and format conversion on each of the 36 inputs. |
| Output Processing | Video proc amps, color correction and format conversion on 12 of the 22 outputs. |
| GPI/O | 34 |
| Ethernet Ports | 2 |
| Reference Inputs | Black or Tri-level |
| Internal Reference Generator | Yes |
| Independently Configurable Reference Outputs | 2 |
–
Operational Features
| OPERATIONAL FEATURES | CARBONITE MOSAIC |
|---|---|
| Compositing / Tile Outputs | 10 tile outputs with 5 layers each ( 1 background and 4 key layers) 10 Program and Preview outputs with “Next Transition” preview of backgrounds and keys |
| Scaling | 18 sub-sampling scaling engines |
| Media Storage | Load stills to any of the 36 inputs as program or back-up sources. |
| Memories | 100 Memories per canvas, with Effect Dissolve and Ross-exclusive MemoryAI functionality. |
| Custom Control Macros | Up to 256 Custom Control Macros, with the ability to run 10 macros simultaneously. |
| Preset & Custom Canvas Layouts | Multiple customizable preset layout choices Create custom canvas layouts Save and recall layouts instantly Individual canvas positioning and adjustment Background scaling Foreground boxes (PIP) Dynamic animated boxes (PIPs) with programmed recall |
| Monitoring | • 3 x 16 window I/O MultiViewer (12 inputs and 4 outputs per MultiViewer) 1 x 10 window layout MultiViewer |
–
Signal Processing Standards
| SIGNAL PROCESSING STANDARDS | CARBONITE MOSAIC |
|---|---|
| Standard Definition | 480i/59.94, 576i/50 |
| High Definition | 720P & 1080i 50/59.94 |
| 1080 PSF | 23.98, 25 & 29.97 |
| 1080p | 29.97 (1.5Gb) & 50/59.94 (3Gb) |
–
Control Interfaces
| CONTROL INTERFACES | CARBONITE MOSAIC |
|---|---|
| Ross Switcher | Mosaic layouts can be recalled directly from a Carbonite or Acuity switcher with the RossTalk protocol. |
| DashBoard | Layouts, memories, and custom controls can be created via network-connected DashBoard software. |
