Carbonite Ultra
Specifications
Carbonite Ultra Frame
| CARBONITE ULTRA STANDARD FEATURES | ||||
|---|---|---|---|---|
| SD/HD | UHD | |||
| SDI Inputs (HD-BNC) | 24 | 18 12G Single Link or 16 Single link +2 Single Link or Quad Link | ||
| (HD-BNC – Standard BNC Adaptors sold separately) | ||||
| NOTE: Internal sources, including MediaStores, ME, MiniME or Aux Bus re-entries, etc. do not reduce the external SDI input matrix. | ||||
| SDI Outputs (HD-BNC) | 12 (10 Assignable & 2 Dedicated MultiViewer) |
11 (10 Assignable & 1 Dedicated MultiViewer) |
||
| (HD-BNC – Standard BNC Adaptors sold separately) | ||||
| Full MEs (Mix/Effects Banks) | Up to 3 | Up to 2 | ||
| MiniMEs | 4 | 2 | ||
| MultiViewers with Tally & Source Names | Up to 4 (Up to 16 windows each) |
Up to 2 (Up to 16 windows each) |
||
| Pattern Generators | 2 per Full ME | |||
| Internal Format Converters/Frame Synchronizers | 8 (Assignable to any input or output) |
2 (Assignable to any input or output) |
||
| Internal Proc Amp/Color Correctors | 8 (Assignable to any input or output) |
2 (Assignable to any input or output) |
||
| 2D DVEs | 8 (Assignable to Full ME Transition Engines Full ME or MiniME Keyers) |
4 (Assignable to Full ME Transition Engines Full ME or MiniME Keyers) |
||
| Keyers per Full ME | 5 (4 Full Keyers + 1 Transition Keyer) |
|||
| Keyers per MiniME | 2 | |||
| UltraChromeTM Chroma-Keyers | 4 (Assignable to any Full ME or MiniME Keyer) |
2 (Assignable to any Full ME or MiniME Keyer) |
||
| MediaStores | 4 (Shared 8GB capacity) |
2 (Shared 8GB capacity) |
||
| Supported Media File Types | .bmp (no alpha) .jpg (no alpha) .tga (with or without alpha .png (with or without alpha 48KHz .wav file |
|||
| USB Media Player | Allows for playout of ITU-T H.264 (MPEG-4 AVC) codec 1280×720 video clips (SD/HD video modes only) | |||
| Animated MediaWipes | Available on all Full MEs | |||
| Effects Memories with Memory AITM | 100 per ME and MiniME | |||
| Custom Control Macros | 256 | |||
| Tallies | 24 | |||
| GPI/O | 24 | |||
| AES Audio Outputs | 2 | |||
| Direct Transfer of XPression Stills to MediaStores via Ethernet | ||||
| LiveEDL (generates a standard Edit Decision List for use in post-production) | ||||
| LIVE CG XPression graphic creation software included (Allows live transfer of XPression still graphics to Carbonite Ultra MediaStores) |
||||
| SUPPORTED VIDEO STANDARDS | ||||
| Standard Definition | 480i 576i |
59.94 (4:3 or 16:9) 50 (4:3 or 16:9) |
||
| High Definition (1.5 Gb/s) | 1080pSF 720p 1080i |
23.98/24/25/29.97/30 50/59.94 50/59.94 |
||
| High Definition (3 Gb/s) | 1080p | 23.98/24/25/29.97/30/50/59.94/60 | ||
| UHD (12Gb/s) | 2160p | 23.98/24/25/29.97/30/50/59.94/60 | ||
| ANALOG REFERENCE INPUT |
|---|
| 1 (HD/BNC) |
| (Tri-Level HD or Analog SD Black Burst) |
| Independent Reference Output (HD/BNC) |
| ANALOG LTC INPUT |
|---|
| 1 |
| (Used with LiveEDL or MultiViewer Clock features) |
| DATA/CONTROL | |
|---|---|
| Ethernet | 1 |
| RS-422 Editor Port | 1 |
| CONTROL INTERFACES |
|---|
| TouchDriveTM Control Panels |
| DashBoard (Virtual Panel or Ultritouch) |
| ViewControlTM – Visual Production Control |
| External RCP Aux Bus Control Panels |
| SUPPORTED CONTROL PROTOCOLS | ||
|---|---|---|
| RossTalkTM | ||
| AMP (Serial over IP) |
||
| Yamaha 01V96 & DM1000 | ||
| TSL UMD 3.1 | ||
| Ross CamBot | ||
| VISCA | ||
| Canon BU Series | ||
| PHYSICAL | ||
| Dimensions | In. | mm |
| Width (Front) | 18.98 | 482.1 |
| Width (Rear) | 17.50 | 444.5 |
| Height | 1.63 | 41.4 |
| Depth | 10.00 | 254.0 |
| Weight | Lbs. | Kgs. |
| Carbonite Ultra 1RU Chassis | 13 | 5.90 |
| Power | Input Voltage | Power Consumption |
| Input Voltage | 100~240V AC, 47-63Hz | 114W – 7.6A – 15V |
| SYSTEM OPTIONS* | |
|---|---|
| SD/HD | UHD |
| Carbonite Ultra Standard Power Supply (Brick) | |
| ULTRIPOWER Rack-mount PSU | |
| Enable ME 2 and UHD ME 1 | |
| Enable ME 3 and UHD ME 2 | |
| Enable MultiViewers 2 & 4 (SD/HD) | Enable MultiViewer 2 |
| Enable Frame Sync/Format Converters, Proc Amps & Color Correctors on all inputs & outputs | Enable 7 assignable Frame Sync/Format Converters, 4 assignable output Format Converters & 7 assignable Proc Amp/Color Correctors |
| HDBNC to BNC adapter cable kit (8 cables) | |
| RAVE AUDIO | |
| Enables comprehensive audio mixing and processing capabilities, including: | |
| 16 audio channels per SDI input | |
| 16 audio channels per SDI output | |
| Up to 24 analog audio inputs* | |
| Up to 15 analog audio outputs* | |
| Up to 3 AES Stereo audio inputs* | |
| Up to 3 AES Stereo audio outputs* | |
| Sample Rate Converters (16-Channel SDI & Stereo AES inputs) | |
| *Requires external Audio Breakout Modules, support up to 3G SDI | |
| AUDIO MIXER STANDARD FEATURES | |
| 48 Stereo Faders | Assignable to any SDI, AES or Analog source |
| Fader Volume | -∞db to + 20db |
| Pre/Post-Fade Audio Meters | |
| Pre/Post-Fade Peak Indicators | |
| Per-Channel EQ & Clip Indicators | |
| Per Channel Mute, Solo, & Pre-Fade Listen (PFL) | |
| Per Channel Mute, Solo, & PFL Clear | |
| Per Fader Audio EQ Control | 4-band (high-shelf, dual midrange, low-shelf) |
| Per Fader Compression/Limiting | Variable Attack & Release parameters (Assignable pre- or post-EQ) |
| Per Fader Audio Follow Video mode | |
| Aux Mixers | 12 – assignable pre- or post-fader |
| Balance Control on Stereo Inputs | |
| Pan Control on Mono Inputs | |
| Mono Mode | Duplication of Mono channel (L or R) to create L-L / R-R channel pair |
| SYSTEM OPTIONS* | |
|---|---|
| RAVE EXTERNAL 1RU AUDIO BREAKOUT MODULE (ABM) | |
| Analog Inputs | 8 |
| Analog Outputs | 5 |
| AES Digital Audio Inputs | 1 |
| AES Digital Audio Outputs | 1 |
| Adjustable Pre-Amps Gain on Analog Inputs | 0-60dB |
| 48V Phantom Power on Analog Inputs | |
| Digital Pads on Analog Inputs | -20dB |
| Number of GPI/O | 24 |
| Number of Tallies | 16 |
| NOTE: All Ultra systems support up to three (3) 1RU Audio Breakout Modules which increases the total analog input matrix to twenty-four (24) and analog output matrix to fifteen (15). | |
| The 1RU Audio Breakout Modules support up to 3G SDI, and are not compatible with Carbonite Ultra in UHD | |
| All Carbonite Ultra systems carry a one-year, full transferable hardware and software warranty. Extended hardware warranties are available on an annual basis. Software maintenance and upgrades are included for the life of the product. | |
*Please contact your Ross Sales Representative for details and pricing for all system options.
